What is the unit and the abbreviation for measuring voltage?
Volts
(V)
Other common values:
millivolt (mV)
microvolt (µV)
kilovolt (kV)
What is the unit and the abbreviation for measuring current?
Amp
(A)
Other common values:
milliamp (mA)
kiloamp (kA)
What is the unit and the abbreviation for measuring power?
Watt
(W)
Other common values:
milliwatt (mW)
kilowatt (kW)
megawatt (MW)
What is the unit and the abbreviation for measuring resistance?
Ohm
(Ω)
Other common values:
kiloohm (kΩ)
megaohm (MΩ)
gigaohm (GΩ)
What kind of resistance is provided by inductors and capacitors?
Reactance, abbreviated X
Inductors supply inductive reactance (XL)
Capacitors supply capacitive reactance (XC)
X is measured in Ω and kΩ
What kind of resistance factors in both the real resistance and the reactance?
Impedance, abbreviated Z.
Z is measured in Ω and kΩ
Is impedance calculated for DC circuits, AC circuits, or both?
AC circuits only
In a DC circuit, the resistance of a capacitor is nearly infinite - an open circuit, so calculating impedance is not useful.
The resistance of an inductor in a DC circuit is nearly 0, so the impedance is equal to the resistance.
What device is used to step voltage up or down in a control system?
A transformer.
Are transformers used with AC voltage, DC voltage, or both?
AC voltage only. The transformer is an inductor, transferring energy by generating a fluctuating magnetic filed that must constantly rise and fall to drive current.
This will not work with DC voltage.
In a series circuit, what is the effect of adding an additional resistor?
The total resistance will increase, and the total current will decrease.
Since the supply voltage did not change, but the current decreased, the total power dissipation will also decrease.
In a parallel circuit, what is the effect of adding an additional resistor?
The total resistance will decrease, and the total current will increase.
Since the supply voltage did not change, but the current increased, the total power dissipation will also increase.
What is the effect on a capacitor as the AC frequency of the circuit increases?
As frequency increases, the capacitive reactance (and overall circuit impedance) will decrease.
What is the effect on a inductor as the AC frequency of the circuit increases?
As frequency increases, the inductive reactance (and overall circuit impedance) will increase.
Explain ‘voltage’.
Voltage is the driving force, caused by the potential energy of a chemical or mechanical reaction, that causes electrons to conduct if given a continuous path (circuit). Sometimes called ‘electro-motive force’, EMF, or simply E.
Explain ‘current’.
Current is the collective unified motion of electrons past a point in a wire, driven by a voltage, and only occurring if given a path, or circuit, from one side of the potential energy source to the other.
Explain ‘resistance’.
Resistance is the opposition to the flow of electrons by causing a change in the form of energy from electrical energy into some other form (commonly heat or light), increasing the voltage required to drive the current.
Explain ‘power’.
Power is the work done, or the energy consumed over a given period of time. Power can be delivered, or supplied into a circuit or system. Power will almost certainly be lost within any real system (efficiency), and as the energy is converted from electrical energy into light, heat, or motion by the ‘load device’, we say the power is dissipated.
